- Heating Mantle Combined unit made of M. steel
- Variable knob for heat power control with on/off.
- Variable Knob for stir speed control with on/off.
- Mantle knitted with glass fibre yarn
- Provides uniform heating to flasks
- For Round Bottomed Flasks as per DIN – 12347
- Easy maintenance
- Single position also available with Metallic Stand 1600.DNEU
Technical Specification:
| Heating Mantle Body | : Made of Mild Steel |
| Heating mantle material | : Glass fibre yarn |
| Mantle Capacity | : To hold Standard round bottom flasks upto 500ml |
| Valuable stirring speed | : 750 RPM |
| Temperature Range | : Approx. 400°C |
| Heating Control | : Electronic power regulator |
| Stir Control | : Electric regulator |
| Dimension | : 495x246x200 |
| Permissible relative moisture | : 80% |
| Permissible Ambient Temperature | : 5-40°C |
| IP Class | : 10 |
Included Accessory:
| Cat. No. | Accessories |
|---|---|
| 2000.200.01 | Vertical Rod stainless steel length 542mm, ∅ 9.8mm |
| 2000.200.02 | Horizontal Rod stainless steel length 972mm, ∅ 9.8mm |
| 2000.200.03 | 5 Boss Head |
| 2000.200.04 | 3 clamp |
Single Soxhlet Extraction with stirrer:
Extraction unit metal stand with heating mantle stirrer
| Model No.
(230V, 50Hz) |
Model No.
(115V, 60Hz) |
Capacity (ml) | Watts | No. of position of regulator |
|---|---|---|---|---|
| 1600.DNEU.01* | 1600.DNUS.01 | 100 | 170 | 1/1 |
| 1600.DNEU.02* | 1600.DNUS.02 | 250 | 170 | 1/1 |
| 1600.DNEU.03* | 1600.DNUS.03 | 500 | 220 | 1/1 |
