- Robust Metallic Construction
- Designed for synchronous heating and stirring
- Suitable for continuous unsupervised operation
- Silicone mat for anti-skid.
- The magnetic coil motorless technology provides noiseless and consistent stirring on all positions
- Homogeneous temperature distribution across the heating plate
- Hot top warning indication
- Timer function
- Multiple modes with mode selection key
- Constant stirring speeds even with viscosity changes
- SPC-mode for a low self-warming of the surface
- Error codes display
Technical Specification:
| Set-up plate material | : Aluminium |
| Number of stirring positions | : 5 |
| Stirring position distance | : 90mm |
| Speed Range |
: 0 – 1000 rpm |
| Stirring quantity max. per stirring position (H2O) | : 2L |
| Silicone Mat | : Yes |
| Stirring bar length max. | : 30mm x 8mm |
| Heating temperature range | : Room temp. – 120°C |
| Input Type | : Key Button |
| Set-up plate dimensions | : 514x122mm |
| Dimensions (W x H x D) | : 600x120x80mm |
| Weight | : 4.5 (Approx.) |
| Permissible ambient temperature |
: 5 – 40°C |
| Permissible relative humidity | : 80% |
| Protection class according to DIN EN 60529 | : IP40 |
| Speed control | : 10 RPM Steps |
| Control display | : LED |
| Adjustable safety circuit min. | : 50°C |
| Adjustable safety circuit max. | : 130°C |
| Timer range | : 00:01 to 99:59 [HH: MM] |
| Temp Control | RPM | Heat & Stir | Choice |
|---|---|---|---|
| upto 120° C | 0-1200 RPM | Setup | 6 Mode |
