- Robust Metallic Construction
- Simultaneously operating stirrers
- Consistent heating and stirring
- Silicone mat for anti-skid
- Homogeneous temperature distribution across the heating plate
- Narrow foot print for space saving
- High magnetic strength
- Knob for electronic variable speed adjustment
- Knob for electronic variable temperature adjustment
- BLDC motor for smooth drive
Technical Specification:
| Set-up plate material | : Aluminium |
| Number of stirring positions | : 5 |
| Stirring position distance | : 90mm |
| Speed Range |
: 0 – 1200 rpm |
| Stirring quantity max. per stirring position (H2O) | : 2L |
| Silicone Mat | : Yes |
| Stirring bar length max. | : 25mm x 9mm |
| Heating temperature range | : Room temp. – 120°C |
| Input Type | : Knob |
| Set-up plate dimensions | : 470x128mm |
| Dimensions (W x H x D) | : 554x126x75mm |
| Weight | : 3 KG |
| Permissible ambient temperature |
: 5 – 40°C |
| Permissible relative humidity | : 80% |
| Protection class according to DIN EN 60529 | : IP40 |
| Temp Control | RPM | Heat & Stir | Choice |
|---|---|---|---|
| upto 120° C | 0-1200 RPM | Setup | 6 Mode |
